百合转录因子<i>MYB12</i>的克隆与表达分析

杨捷; 张星; 彭梦笛; 贾桂霞; 何恒斌

doi:10.11913/PSJ.2095-0837.2018.60812

百合转录因子MYB12的克隆与表达分析

北京林业大学园林学院, 花卉种质创新与分子育种北京市重点实验室, 国家花卉工程技术研究中心, 城乡生态环境北京实验室, 北京 100083

基金项目:

国家自然科学基金项目（31672191）；中央高校基本科研业务费专项（YX2015-16）。

详细信息

作者简介:
杨捷(1994-),女,硕士研究生,研究方向为花卉分子生物学(E-mail:jieyang@bjfu.edu.cn)。

通讯作者:
何恒斌,E-mail:hengbinhe_1220@bjfu.edu.cn

中图分类号: Q943.2
计量
- 文章访问数: 705
- HTML全文浏览量: 1
- PDF下载量: 857
出版历程
- 收稿日期: 2018-04-26
- 网络出版日期: 2022-10-31
- 发布日期: 2018-12-27

Cloning and expression analysis of MYB12 in Lilium oriental hybrid ‘Sorbonne’

Beijing Key Laboratory of Ornamental Plants Germplasm Innovation and Molecular Breeding, National Engineering Research Center for Floriculture and Beijing Laboratory of Urban and Rural Ecological Environment, College of Landscape Architecture, Beijing Forestry University, Beijing 100083, China

Funds:

This work was supported by grants from the National Natural Science Foundation of China (31672191) and Fundamental Research Funds for the Central Universities (YX2015-16).

摘要

摘要: 以东方百合‘索邦’（Lilium oriental hybrid ‘Sorbonne’）为材料，克隆获得花青素苷生物合成通路中的关键转录因子LhsorMYB12基因。序列分析结果显示，LhsorMYB12最大开放阅读框长720 bp，编码239个氨基酸，具有2个典型的DNA结合结构域；该基因包括3个外显子和2个内含子。该基因的氨基酸序列与郁金香（Tulipa fosteriana W.Irving）中的MYB氨基酸序列相似性最高。系统进化分析结果表明，LhsorMYB12在MYB基因家族中与已报道的控制花青素苷合成的基因形成一簇。进一步采用染色体步移技术，获得了LhsorMYB12基因起始密码子上游2143 bp的启动子序列，顺式作用元件预测结果显示，该序列中除核心启动子元件（TATA box）外，还包含有MYB蛋白的绑定位点、光反应元件以及参与昼夜节律等反应的相关元件。基因表达分析结果表明，LhsorMYB12仅在‘索邦’花丝、花柱和花被片中表达；且在花蕾发育过程中表达量逐渐增高，花蕾盛开时表达量最大，但内、外花被的表达起始阶段不同。黑暗处理可导致LhsorMYB12表达水平降低；光照条件下该基因的表达水平随处理时间的延长表现出先上升后下降再持续上升的趋势。研究结果提示LhsorMYB12的表达变化规律可能与其启动子中相应的顺式作用元件相关。
- 东方百合‘索邦’ /
- MYB基因 /
- 花青素苷 /
- 克隆 /
- 启动子 /
- 基因表达
Abstract: To reveal the regulatory mechanism of the anthocyanin synthesis pathway in Lilium, we isolated cDNA, gDNA, and the MYB12 gene promoter from the petals of the L. oriental hybrid ‘Sorbonne’. Results showed that the cDNA sequence contained a 720 bp open reading frame (ORF) encoding a 239 amino acid polypeptide with two typical DNA-binding domains. The 863 bp nucleotide sequence was amplified from the extracted DNA and the gene consisted of three exons and two introns. Furthermore, the amino acid sequence had highest similarity with MYB transcription factors in Tulipa fosteriana W. Irving. Phylogenetic analysis showed that the phylogenetic evolution of the transcription factor was in accordance with taxonomic classification, and it could be grouped with genes that regulate anthocyanin biosynthesis in the MYB gene family. The 2143 bp promoter sequence of the LhsorMYB12 gene was obtained using chromosome walking technology. The promoter element prediction results showed the existence of a core promoter element (TATA box), MYB protein binding sites, photoreactive elements, and other regulation motifs (e.g., circadian rhythm response motif). RT-PCR analysis indicated that the expression of LhsorMYB12 could be detected in the tepals, filaments, stigmas, and styles. qRT-PCR analysis showed that the relatively high expression occurred in blooming period (12 cm) tepals, and then began to decrease. However, there was a difference between the initial stage of expression in the inner and outer perianths. Moreover, dark treatment resulted in a reduction in the expression of LhsorMYB12, with the lowest expression found after an hour of treatment. Under light conditions, the expression level of the gene increased at first, then decreased, and then continued to rise with increasing treatment time. The LhsorMYB12 expression pattern results might relate to the corresponding cis-acting elements in its promoter.
- Lilium oriental hybrid ‘Sorbonne’ /
- MYB gene /
- Anthocyanins /
- Cloning /
- Promo-ter /
- Gene expression

HTML全文

参考文献(40)

[1]	王秀刚. 百合种质资源的花色评价及形成的分析[D]. 哈尔滨:东北农业大学, 2012.
[2]	Wang ZG, Meng D, Wang AD, Li T, Jiang S, et al. The methylation of the PcMYB10 promoter is associated with green-skinned sport in Max Red Bartlett pear[J]. Plant Physiol, 2013, 162:885-896.
[3]	Koes R, Verweij W, Quattrocchio F. Flavonoids:a colorful model for the regulation and evolution of biochemical pathways[J]. Trends Plant Sci, 2005, 10(5):236-242.
[4]	戴思兰, 洪艳. 基于花青素苷合成和呈色机理的观赏植物花色改良分子育种[J]. 中国农业科学, 2016, 49(3):529-542. Dai SL, Hong Y. Molecular breeding for flower colors modification on ornamental plants based on the mechanism of anthocyanins biosynthesis and coloration[J]. Scientia Agricultura Sinica, 2016, 49(3):529-542.
[5]	王瑜, 崔金腾, 张克中, 贾月慧. 百合花青素苷合成酶基因片段的克隆及表达分析[J]. 中国农学通报, 2013, 29(10):162-166. Wang Y, Cui JT, Zhang KZ, Jia YG. Molecular cloning and expression analysis of anthocyanidin synthase gene fragment in Lilium[J].Chinese Agricultural Science Bulletin, 2013, 29(10):162-166.
[6]	孔滢, 窦晓莹, 包放, 郎利新, 白锦荣. 百合花色机理研究进展[J]. 园艺学报, 2015, 42(9):1747-1759. Kong Y, Dou XY, Bao F, Lang LX, Bai JR. Advances in flower color mechanism of Lilium[J]. Acta Horticulturae Sinica, 2015, 42(9):1747-1759.
[7]	黄洁, 刘晓华, 管洁, 吕英民. 百合分子育种研究进展[J]. 园艺学报, 2012, 39(9):1793-1808. Huang J, Liu XH, Guan J, Lü YM. Progress in molecular breeding of lily[J]. Acta Horticulturae Sinica, 2012, 39(9):1793-1808.
[8]	杨丽. 百合查尔酮合成酶基因(CHS)及其启动子的克隆与分析[D]. 杨凌:西北农林科技大学, 2006.
[9]	常小丽. 百合查尔酮合成酶基因花特异启动子的功能分析[D]. 杨凌:西北农林科技大学, 2008.
[10]	化占勇. 百合查尔酮合成酶(CHS)基因对花色调控影响的研究[D]. 杨凌:西北农林科技大学, 2010.
[11]	娄倩. 百合花色形成关键基因(CHS)启动子功能分析[D]. 杨凌:西北农林科技大学, 2010.
[12]	陈洁, 安利清, 王涛, 姚娜, 李璐滨, 等. 百合查尔酮合成酶基因克隆及其转化烟草的花色表达分析[J]. 西北植物学报, 2012, 32(8):1511-1517. Chen J, An LQ, Wang T, Yao N, Li LB, et al. Cloning of chalcone synthase gene in Lilium and expression analysis of flower colour changes in transgenic tobacco[J]. Acta Botanica Boreali-Occidentalia Sinica, 2012, 32(8):1511-1517.
[13]	窦晓莹, 郎利新, 包放, 孔滢, 尚宏忠,等. 东方百合查尔酮异构酶基因LhCHI的克隆及表达[J]. 东北林业大学学报, 2015, 43(9):6-11. Dou XY, Lang LX, Bao F, Kong Y, Shang HZ, et al. Cloning and expression analysis of chalcone isomerase gene LhCHI in oriental hybrid lily (Lilium spp.)[J]. Journal of Northeast Forestry University, 2015, 43(9):6-11.
[14]	阴婷. 垂花百合花青素基因ANS启动子的克隆及功能分析[D]. 沈阳:沈阳农业大学, 2016.
[15]	Yamagishi M, Shimoyamada Y, Nakatsuka T, Masuda K. Two R2R3-MYB genes, homologs of petunia AN2, regulate anthocyanin biosyntheses in flower tepals, tepal spots and leaves of Asiatic hybrid lily[J]. Plant Cell Physiol, 2010, 51:463-474.
[16]	Yamagishi M, Yoshida Y, Nakatsuka M. The transcription factor LhMYB12 determines anthocyanin pigmentation in the tepals of Asiatic hybrid lilies (Lilium spp.) and regulates pigment quantity[J]. Mol Breeding, 2012, 30:913-925.
[17]	Yamagishi M, Toda S, Tasaki K. The novel allele of the LhMYB12 gene is involved in splatter-type spot formation on the flower tepals of Asiatic hybrid lilies (Lilium spp.)[J]. New Phytol, 2014, 201(3):1009-1020.
[18]	马春雷, 姚明哲, 王新超, 金基强, 陈亮. 茶树2个MYB转录因子基因的克隆及表达分析[J]. 林业科学, 2012, 48(3):31-37. Ma CL, Yao MZ, Wang XC, Jin JQ, Chen L. Cloning and expression of two MYB transcription factors in tea plant (Camellia sinensis)[J]. Scientia Silvae Sinicae, 2012, 48(3):31-37.
[19]	Du H, Feng BR, Yang SS, Huang YB, Tang YX. The R2R3-MYB transcription factor gene family in maize[J]. PLoS One, 2012, 7(6):e37463.
[20]	Chen YH, Yang XY, He K, Liu MH, Li JG, et al. The MYB transcription factor superfamily of Arabidopsis:expression analysis and phylogenetic comparison with the rice MYB family[J]. Plant Mol Biol, 2006, 60:107-124.
[21]	Baumann K, Perez-Rodriguez M, Bradley D, Venail J, Bailey P, Jin H, et al. Control of cell and petal morphogenesis by R2R3 MYB transcription factors[J]. Development, 2007, 134(9):1691-1701.
[22]	曲丰佳, 安建平, 姚继芳, 李浩浩, 李媛媛, 等. 苹果MdMYB2 基因的克隆及功能鉴定[J]. 园艺学报, 2017, 44(12):2245-2254. Qu FJ, An JP, Yao JF, Li HH, Li YY, et al. Gene cloning and functional identification of an apple MdMYB2 gene[J]. Acta Horticulturae Sinica, 2017, 44(12):2245-2254.
[23]	Allan AC, Hellen RP, Laing WA. MYB transcription factors that colour our fruit[J]. Trends Plant Sci, 2008, 13(3):99-102.
[24]	Feng SQ, Wang YL, Yang S, Xu YT, Chen XS. Anthocyanin biosynthesis in pears is regulated by a R2R3-MYB transcription factor PyMYB10[J]. Planta, 2010, 232(1):245.
[25]	Jackson D, Culianez-macia F, Prescott AG, Roberts K, Martin C. Expression patterns of myb genes from Antirrhinum flowers[J]. Plant Cell, 1991, 3(2):115.
[26]	Mathews H, Clendennen SK, Caldwell CG, Liu XL, Connors K, et al. Activation tagging in tomato identifies a transcriptional regulator of anthocyanin biosynthesis, modification, and transport[J]. Plant Cell, 2003, 15(8):1689-1703.
[27]	Espley RV, Hellen RP, Putterill J, Stevenson DE, Kutty-Amma S, et al. Red colouration in apple fruit is due to the activity of the MYB transcription factor, MdMYB10[J]. Plant J, 2007, 49(3):414.
[28]	Schwinn KE, Boase MR, Bradley JM, Lewis DH, Deroles SC, et al. MYB and bHLH transcription factor transgenes increase anthocyanin pigmentation in petunia and lisianthus plants, and the petunia phenotypes are strongly enhanced under field conditions[J]. Front Plant Sci, 2014, 5(603):1-11.
[29]	Lotkowska ME, Tohge T, Fernie AR. The Arabidopsis transcription factor MYB112 promotes anthocyanin formation during salinity and under high light stress[J]. Plant Physiol, 2015, 169(3):1862-80.
[30]	Quattrocchio F, Wing J, Woude K, Souer E, De VN, et al. Molecular analysis of the anthocyanin2 gene of petunia and its role in the evolution of flower color[J]. Plant Cell, 1999, 11:1433-1444.
[31]	Elomaa P, Uimari A, Mehto M, Albert VA, Laitinen RA, et al. Activation of anthocyanin biosynthesis in Gerbera hybrid (Asteraceae) suggests conserved protein-protein and protein-promoter interactions between the anciently diverged monocots and eudicots[J]. Plant Physiol, 2003, 133:1831-1842.
[32]	Schiwinn K, Venail J, Shang YJ, Mackay S, Alm V, et al. A small family of MYB-regulatory genes controls floral pigmentation intensity and patterning in the genus Antirrhinum[J]. Plant Cell, 2006, 18:831-851.
[33]	Mano H, Ogasawara F, Sato K, Higo H, Minobe Y. Isolation of a regulatory gene of anthocyanin biosynthesis in tuberous roots of purple-fleshed sweet potato[J]. Plant Physiol, 2007, 143:1252-1268.
[34]	Gonzalez A, Zhao M, Leavitt JM, Lloyd AM. Regulation of the anthocyanin biosynthetic pathway by the TTG1/bHLH/Myb transcriptional complex in Arabidopsis seedlings[J]. Plant J, 2008, 53:814-827.
[35]	Pattanaik S, Yuan L. Isolation and functional characterization of a floral tissue-specific R2R3 MYB regulator from tobacco[J]. Planta, 2010, 231:1061-1076.
[36]	Fournier-level A, Lacombe T, Le CL, Boursiquot JM, This P. Evolution of the VvMybA gene family, the major determinant of berry colour in cultivated grapevine (Vitis vinifera L.)[J]. Heredity, 2010, 104:351-362.
[37]	Chiu LW, Zhou XJ, Burke S, Wu X, Prior RL, et al. The purple cauliflower arises from activation of a MYB transcription factor[J]. Plant Physiol, 2010, 154:1470-1480.
[38]	袁媛. 郁金香花色苷合成基因的克隆及其表达差异与花色变化的关系[D]. 上海:上海交通大学, 2015.
[39]	韩晓敏, 邢丹丹, 杨杞, 李国婧, 王瑞刚. 中间锦鸡儿CiMYB177 的克隆及表达分析[J]. 植物生理学报, 2016, 52(5):635-644. Han XM, Xing DD, Yang Q, Li GJ, Wang RG. Cloning and expression analysis of CiMYB177 from Caragana intermedia[J]. Plant Physiology Journal, 2016, 52(5):635-644.
[40]	Li KT, Zhang J, Kang YH, Chen MC, Song TT. McMYB10 modulates the expression of a ubiquitin ligase, McCOP1 during leaf coloration in crabapple[J]. Front Plant Sci, 2018, 9(704):1-14.
