黄秆乌哺鸡竹转录组EST-SSR分子标记开发与应用

娄永峰; 甘然; 朱成磊; 肖复明; 高志民

doi:10.11913/PSJ.2095-0837.2022.30355

黄秆乌哺鸡竹转录组EST-SSR分子标记开发与应用

1. 江西省林业科学院, 江西省植物生物技术重点实验室, 南昌 330032;
2. 国际竹藤中心, 国家林业和草原局/北京市竹藤科学与技术重点开放实验室, 北京 100102

基金项目:

国家林木种质资源共享服务平台(2005DKA21003)；国际竹藤中心基本科研业务费专项(1632020004)。

详细信息

作者简介:
娄永峰(1983-)，男，博士，副研究员，研究方向为林木遗传育种与森林培育(E-mail:330403612@qq.com)。

通讯作者:
高志民,E-mail:gaozhimin@icbr.ac.cn

中图分类号: Q943.2
计量
- 文章访问数: 317
- HTML全文浏览量: 3
- PDF下载量: 249
出版历程
- 收稿日期: 2021-11-08
- 修回日期: 2021-12-24
- 网络出版日期: 2022-10-31
- 发布日期: 2022-06-27

Development and application of EST-SSR markers based on transcriptome of Phyllostachys vivax McClure f. aureocaulis N. X. Ma

1. Jiangxi Provincial Key Laboratory of Plant Biotechnology, Jiangxi Academy of Forestry, Nanchang 330032, China;
2. State Forestry and Grassland Administration/Beijing Key Laboratory on the Science and Technology of Bamboo and Rattan, International Center for Bamboo and Rattan, Beijing 100102, China

Funds:

This work was supported by grants from the National Forest Genetic Resources Platform (2005DKA21003) and Fundamental Scientific Research on Professional Work Supported by the International Center for Bamboo and Rattan (1632020004).

摘要

摘要: 基于黄秆乌哺鸡竹(Phyllostachys vivax McClure f. aureocaulis N. X. Ma)转录组数据，利用生物信息学方法分析其SSR位点分布特征，同时针对“黄秆”和“绿秆”两种类型差异表达基因序列中的SSR位点设计引物，并利用刚竹属(Phyllostachys)材料验证其通用性。结果显示，从黄秆乌哺鸡竹89 874个Unigenes序列中，共鉴定出12 651个SSR位点，分布频率为14.07%；其中单核苷酸重复基序最多(51.02%)、其次为3核苷酸(25.61%)和2核苷酸(21.94%)；共发现80种重复基序，其中出现频率最高的为A/T(46.60%)，其次是AG/CT(13.97%)和CCG/CGG(9.90%)。在设计的51对引物中，44对(86.27%)能有效扩增，在刚竹属材料中平均通用性为92.41%，其中39对具有多态性，多态性EST-SSR标记能区分同属的不同种，但不能有效区分种内种质资源。
- 黄秆乌哺鸡竹 /
- 转录组 /
- EST-SSR标记 /
- 通用性
Abstract: Based on transcriptome data of Phyllostachys vivax McClure f. aureocaulis N. X. Ma, the distribution and characteristics of simple sequence repeat (SSR) loci were analyzed using bioinformatics. Primers were designed according to the SSR loci in the differentially expressed genes between the “yellow culm type” and “green culm type”. The validity and transferability of the primers within the Phyllostachys genus were determined using samples from Phyllostachys species. Results showed that 12 651 SSR loci were detected in 89 874 unigene sequences of Ph.vivax f. aureocaulis, with a frequency of 14.07%. Among the SSR loci, mononucleotide repeat motifs were the most abundant (51.02%), followed by trinucleotide and dinucleotide repeat motifs (25.61% and 21.94%, respectively). Of the 80 repeat motifs found, the most abundant was A/T (46.60%), followed by AG/CT (13.97%) and CCG/CGG (9.90%). Based on the SSR loci of differentially expressed genes between the “yellow culm type” and “green culm type”, a total of 51 primer pairs were designed, 44 (86.27%) of which were able to amplify the expected polymerase chain reaction (PCR) products. Average transferability of the 44 primers pairs in the selected Phyllostachys species was 92.41%, with 39 pairs containing interspecific polymorphisms. These polymorphic-expressed sequence tag-derived EST-SSR markers could effectively distinguish different bamboo species in Phyllostachys but could not effectively distinguish intraspecific germplasm resources.
- Phyllostachys vivax /
- Transcriptome /
- EST-SSR markers /
- Transferability

HTML全文

参考文献(36)

[1]	尹跃,安巍,赵建华,王亚军,樊云芳,曹有龙.黑果枸杞转录组SSR信息分析及分子标记开发[J].浙江农林大学学报, 2019, 36(2):422-428. Yin Y, An W, Zhao JH, Wang YJ, Fan YF, Cao YL. SSR information in transcriptome and development of molecular markers in Lycium ruthenicum[J]. Journal of Zhejiang A&F University, 2019, 36(2):422-428.
[2]	陈昌龙,董岩,田宇,石妙涵,葛秀秀,谢华.芹菜转录组数据SSR标记的开发及其遗传多样性分析[J].农业生物技术学报, 2020, 28(4):616-628. Chen CL, Dong Y, Tian Y, Shi MH, Ge XX, Xie H. TranscriptomicSSR marker development and genetic diversity analysis in celery (Apium graveolens)[J]. Journal of Agricultural Biotechnology, 2020, 28(4):616-628.
[3]	郭俊,朱婕,谢尚潜,张叶,叶蓓蕾,等.油梨转录组SSR分子标记开发与种质资源亲缘关系分析[J].园艺学报, 2020, 47(8):1552-1564. Guo J, Zhu J, Xie SQ, Zhang Y, Ye BL, et al. Development of SSR molecular markers based on transcriptome and analysis of genetic relationship of germplasm resources in avocado[J]. Acta Horticulturae Sinica, 2020, 47(8):1552-1564.
[4]	李青竹,蔡友铭,张永春,许俊旭,杨柳燕,孙翊.基于石蒜属转录组序列的SSR分子标记开发应用[J].核农学报, 2021, 35(9):2002-2015. Li QZ, Cai YM, Zhang YC, Xu JX, Yang LY, Sun Y. Development and application of SSR molecular markers based on transcriptome sequencing of Lycoris spp.[J]. Journal of Nuclear Agricultural Sciences, 2021, 35(9):2002-2015.
[5]	李延龙,张华敏,崔蕴刚,陈建华,吕爱芹,等.韭菜全长转录组SSR信息分析及分子标记开发[J].园艺学报, 2020, 47(4):759-768. Li YL, Zhang HM, Cui YG, Chen JH, Lv AQ, et al. Analysis on SSR information in full-length transcriptome and development of molecular markers in Allium tuberosum[J]. Acta Horticulturae Sinica, 2020, 47(4):759-768.
[6]	蔡年辉,许玉兰,王大玮,唐红燕,李根前.思茅松EST-SSR标记在几种松属植物中的通用性分析[J].西南林业大学学报, 2017, 37(4):8-14. Cai NH, Xu YL, Wang DW, Tang HY, Li GQ. The transferability analysis of Pinus kesiya var. langbianensis EST-SSR markers to several pine species[J]. Journal of Southwest Forestry University, 2017, 37(4):8-14.
[7]	陆云峰,杨安娜,张俊红,楼炉焕,黄华宏,童再康.紫楠转录组EST-SSR标记开发及通用性分析[J].农业生物技术学报, 2018, 26(6):1014-1024. Lu YF, Yang AN Zhang JH, Lou LH, Huang HH, Tong ZK. Development and transferability evaluation of EST-SSR markers based on transcriptome data of Phoebe sheareri[J]. Journal of Agricultural Biotechnology, 2018, 26(6):1014-1024.
[8]	龚桂芳,冯源恒,安琪,杨章旗.马尾松候选基因EST-SSR引物开发[J].分子植物育种, 2020, 18(23):7840-7846. Gong GF, Feng YH, AN Q, Yang ZQ. EST-SSR primer development based on Pinus massoniana candidate gene[J]. Molecular Plant Breeding, 2020, 18(23):7840-7846.
[9]	Tong Y, Gao LZ. Development and characterization of EST-SSR markers for Camellia reticulate[J]. Appl Plant Sci, 2020, 8(5):e11348.
[10]	Liu QQ, Lu ZY, He W, Li F, Chen WN, et al. Development and characterization of 16 novel microsatellite mar-kers by transcriptome sequencing for Angelica dahurica and test for cross-species amplification[J]. BMC Plant Biol, 2020, 20:152.
[11]	易敏,张露,雷蕾,程子珊,孙世武,赖猛.湿地松转录组SSR分析及EST-SSR标记开发[J].南京林业大学学报(自然科学版), 2020, 44(2):75-83. Yi M, Zhang L, Lei L, Cheng ZS, Sun SW, Lai M. Analysis of SSR information in transcriptome and development of EST-SSR molecular markers in Pinus elliottii Engelm.[J]. Journal of Nanjing Forestry University (Natural Sciences Edition), 2020, 44(2):75-83.
[12]	刘粉粉,徐刚标,李恬甜,罗常莎.伯乐树转录组SSR分布特征及其引物开发[J].植物科学学报, 2021, 39(3):288-296. Liu FF, Xu GB, Li TT, Luo CS. Characterization and development and of SSR markers from transcriptome sequences of Bretschneidera sinensis Hemsl.[J]. Plant Science Journal, 2021, 39(3):288-296.
[13]	马丽莎,史军义,易同培,杨汉奇,杨林.中国竹亚科植物的耐寒区位区划[J].林业科学研究, 2011, 24(5):627-633. Ma LS, Shi JY, Yi TP, Yang HQ, Yang L. The cold hardiness location of Bambusoideae in China[J].Forest Research, 2011, 24(5):627-633.
[14]	郭小勤,李犇,阮晓赛,娄永峰,林新春,等.利用ACGM分子标记研究10个毛竹不同栽培变种的遗传多样性[J].林业科学, 2009, 45(4):28-32. Guo XQ, Li B, Ruan XS, Lou YF, Lin XC, et al. Genetic diversity of ten Phyllostachys edulis cultivars with ACGM Markers[J]. Scientia Silvae Sinicae, 2009, 45(4):28-32.
[15]	Jiang WX, Bai TD, Dai HM, Wei Q, Zhang WJ, Ding YL. Microsatellite markers revealed moderate genetic diversity and population differentiation of moso bamboo (Phyllostachys edulis)-a primarily asexual reproduction species in China[J]. Tree Genet Genomes, 2017, 13:130.
[16]	CaI K, Zhu LF, Zhang KK, Li L, Zhao ZY, et al. Development and characterization of EST-SSR markers from RNA-Seq data in Phyllostachys violascens[J]. Front Plant Sci, 2019, 10:50.
[17]	黄蕾,邢晓成,张雨曲,任毅.地理因素对箭竹复合体遗传多样性与遗传分化的影响[J].西北植物学报, 2021, 41(5):872-879. Huang L, Xing XC, Zhang YQ, Ren Y. Effect of geographic factors on the genetic diversity and divergence of Fargesia spathacea complex[J]. Acta Botanica Boreali Occidentalia Sinica, 2021, 41(5):872-879.
[18]	娄永峰,杨海芸,张有珍,李晓芬,林新春,方伟.部分竹类植物遗传变异的AFLP, SSR和SRAP分析[J].福建林学院学报, 2011, 31(1):38-43. Lou YF, Yang HY, Zhang YZ, Li XF, Lin XC, Fang W. Analysis of genetic variation of some bamboo species by AFLP, ISSR and SRAP[J]. Journal of Fujian College of Forestry, 2011, 31(1):38-43.
[19]	张培新,张洪亮,陈贤喜,卓海潮,周锐.中国名优竹-黄秆乌哺鸡[M].杭州:浙江科学技术出版社, 2013:10-21.
[20]	高志民,范少辉,高健,李雪平,蔡春菊,彭镇华.基于CTAB法提取毛竹基因组DNA的探讨[J].林业科学研究, 2006, 19(6):725-728. Gao ZM, Fan SH, Gao J, Li XP, Cai CJ, Peng ZH. Extract genomic DNA from Phyllostachys edulis by CTAB-based method[J]. Forest Research, 2006, 19(6):725-728.
[21]	Peng ZH, Lu TT, Li LB, Liu XH, Gao ZM, et al. Genome-wide characterization of the biggest grass, bamboo, based on 10608 putative full-length cDNA sequences[J]. BMC Plant Biol, 2010, 10:116.
[22]	Lin Y, Lu JJ, Wu MD, Zhou MB, Fang W, et al. Identification, cross-taxon transferability and application of full-length cDNA SSR markers in Phyllostachys pubescens[J]. Springer Plus, 2014, 3:486.
[23]	鞠烨,江建平,尹增芳,魏强.孝顺竹笋箨全长转录组测序分析[J].南京林业大学学报(自然科学版), 2020, 44(6):175-183. Ju Y, Jiang JP, Yin ZF, Wei Q. Full-length transcriptome sequencing and annotation analyses of Bambusa multiplex sheath[J]. Journal of Nanjing Forestry University (Natural Sciences Edition), 2020, 44(6):175-183.
[24]	Cui K, Wang HY, Liao SX, Tang Q, Li L, et al. Transcriptome sequencing and analysis for culm elongation of the world's largest bamboo (Dendrocalamus sinicus)[J]. PLoS One, 2016, 11(6):e0157362.
[25]	Liu MY, Qiao GR, Jiang J, Yang HQ, Xie LH, et al. Transcriptome sequencing and de novo analysis for Ma bamboo (Dendrocalamus latiflorus Munro) using the Illumina platform[J]. PLoS One, 2012, 7(10):e46766.
[26]	胡文舜,陈秀萍,郑少泉.龙眼EST-SSR标记开发及无患子科5个属种质遗传多样性分析[J].园艺学报, 2019, 46(7):1359-1372. Hu WS, Chen XP, Zheng SQ. EST-SSR markers deve-loped from Dimocarpus longan and their application in genetic diversity analysis of five genera of Sapindaceae[J]. Acta Horticulturae Sinica, 2019, 46(7):1359-1372.
[27]	张振,张含国,莫迟,张磊.红松转录组SSR分析及EST-SSR标记开发[J].林业科学, 2015, 51(8):114-120. Zhang Z, Zhang HG, Mo C, Zhang L. Transcriptome sequencing analysis and development of EST-SSR Markers for Pinus koraiensis[J]. Scientia Silvae Sinicae, 2015, 51(8):114-120.
[28]	Rota ML, Kantety RV, YU JK, Sorrells ME. Nonrandom distribution and frequencies of genomic and EST-derived microsatellite markers in rice, wheat, and barley[J]. BMC Genomics, 2005, 6:23.
[29]	郑燕,张耿,吴为人.禾本科植物微卫星序列的特征分析和比较[J].基因组学与应用生物学, 2011, 30(5):513-520. Zheng Y, Zhang G, Wu WR. Characterization and comparison of microsatellites in Gramineae[J].Genomics and Applied Biology, 2011, 30(5):513-520.
[30]	彭镇华,刘贯水,李潞滨.磁珠富集法开发毛竹SSR标记引物[J].林业科学研究, 2011, 24(6):743-748. Peng ZH, Liu GS, Li LB. Development of polymorphic simple sequence repeats markers in Phyllostachys edulis by magnesphere[J]. Forest Research, 2011, 24(6):743-748.
[31]	Zhao HS, Yang L, Peng ZH, Sun HY, Yue XH, et al. Developing genome-wide microsatellite markers of bamboo and their applications on molecular marker assisted taxo-nomy for accessions in the genus Phyllostachys[J]. Sci Rep, 2015, 5:8018.
[32]	高志民,杨丽,李彩丽,刘青.麻竹EST-SSR标记开发及其对慈竹变异类型的分析研究[J].热带亚热带植物学报, 2012, 20(5):462-468. Gao ZM, Yang L, Li CL, Liu Q. EST-SSR molecular mar-ker development from Dendrocalamus latiflorus and its application on genetic diversity analysis of variation types from Bambusa emeiensis[J]. Journal of Tropical and Subtropical Botany, 2012, 20(5):462-468.
[33]	杜伟,王东航,侯思宇,韩渊怀,李红英,等.基于苦荞全长转录组测序开发SSR标记及遗传多样性分析[J].植物生理学报, 2020, 56(7):1432-1444. Du W, Wang DH, Hou SY, Han YH, Li HY, et al. Deve-lopment of SSR markers based on full-length transcriptome sequencing and its application for genetic diversity analysis in Fagopyrum tataricum[J]. Plant Physiology Journal, 2020, 56(7):1432-1444.
[34]	杨丽,管雨,张智俊.竹类植物EST-SSRs分布特征及应用[J].农业生物技术学报, 2011, 19(1):57-62. Yang L, Guan Y, Zhang ZJ. Characterization and utilization of EST-SSRs markers from bamboo[J]. Journal of Agricultural Biotechnology, 2011, 19(1):57-62.
[35]	Lv Y, Yu T, Lu SH, Cheng T, Li JQ, Du FK. Development of microsatellite markers for Fargesia denudata (Poa-ceae), the staple-food bamboo of the giant panda[J]. Appl Plant Sci, 2016, 4(6):1600005.
[36]	Bhandawat A, Sharma V, Sharma H, Sood A, Sharma RK. Development and cross-transfer ability of functionally relevant microsatellite markers in Dendrocalamus latiflorus and related bamboo species[J]. J Genet, 2014, 93(2):48-55.
